[게임엔진활용] 8강 사과 게임 제작

사과 게임 제작

- 플래그값을 통한 게임씬 전환

- 버튼 제작

using System;
using UnityEngine;

public class GameScene : RenderView
{
    int gameState;// 0:title, 1:inGame

    public override void load()
    {
        gameState = 0;
        loadTitle();
    }

    public override void free()
    {
        switch (gameState)
        {
            case 0: freeTitle(); break;
            case 1: freeIngame(); break;
        }
    }

    public override void draw(float dt)
    {
        switch (gameState)
        {
            case 0: drawTitle(dt); break;
            case 1: drawIngame(dt); break;
        }
    }

    public override void mouse(int state, float x, float y)
    {
        switch (gameState)
        {
            case 0: mouseTitle(state, x, y); break;
            case 1: mouseIngame(state, x, y); break;
        }
    }

    // backgroud, button(play)
    Texture texLogo;
    struct Button
    {
        public Rect rt;
        public string s;
        public bool pressed;
        public Color cb;
        public Color ch;
        public Color cf;
        public float size;
    }
    Button btnPlay;

    void loadTitle()
    {
        texLogo = createImage("logo");

        Button b = new Button();
        b.rt = new Rect(10, 10, 400, 300);
        b.s = "Play";
        b.pressed = false;
        b.cb = Color.red;// 기본
        b.ch = Color.blue;// 커서
        b.cf = Color.white;
        b.size = 300;
        btnPlay = b;

    }

    void freeTitle()
    {

    }

    void drawButton(Button b)
    {
        Rect rt = b.rt;

        Color c = b.pressed ? b.ch : b.cb;
        setRGBA(c.r, c.g, c.b, c.a);
        fillRect(rt.x, rt.y, rt.width, rt.height);
        setRGBA(1, 1, 1, 1);

        setStringName("굴림");
        float stringSize = b.size;
        setStringSize(stringSize);
        Vector2 size = sizeOfString(b.s);
        if (size.x > rt.width)
            setStringSize(stringSize * rt.width / size.x);
        setStringRGBA(b.cf.r, b.cf.g, b.cf.b, b.cf.a);
        drawString(b.s, rt.x + rt.width / 2,
                                rt.y + rt.height / 2, VCENTER | HCENTER);

    }

    Image hero = null;

    void drawTitle(float dt)
    {
        float rx = (float)mc.devWidth / texLogo.width;
        float ry = (float)mc.devHeight / texLogo.height;
        drawImage(texLogo, 0, 0, 0, 0, texLogo.width, texLogo.height,
            TOP | LEFT, rx, ry);

        drawButton(btnPlay);

        if (hero == null)
        {
            hero = new Image(this);

            Texture[] texs = createImage(4, 1, "hero40");
            int[] idx = {
            1, 2, 3,    1, 2, 3,   0, 2, 3,
            1, 2, 3,    1, 2, 3,   1, 2, 3,   0, 2, 3,
            };
            for (int i = 0; i < idx.Length; i++)
                hero.add(texs[idx[i]]);
            hero._aniDt = 0.18f;
            hero.position = new Vector2(-72, -200);
            hero.startAnimation(true);
        }

        //for (int i = 0; i < 4; i++)
        //{
        //    drawImage(texHero[i], 100 * i, 120 * i, TOP | LEFT);
        //}
        hero.paint(dt, new Vector2(100, 120));
    }

    public void mouseTitle(int state, float x, float y)
    {
        switch (state)
        {
            case 0:
                if (btnPlay.pressed)
                {
                    gameState = 1;
                    freeTitle();
                    loadIngame();
                }
                break;
            case 1:
                btnPlay.pressed = containPoint(x, y, btnPlay.rt);
                break;
        }

    }

    Button[] apple;
    //int score;
    AutoNumber score;
    float playTime, _playTime;
    ProgressBar progressBar;

    bool gameOver;
    Button[] btnResult;
    public static Color cGreen = new Color(0.1f, 0.5f, 0.0f, 1.0f);

    void loadIngame()
    {
        // 60 * 15
        float x = (mc.devWidth - 60 * 15) / 2;
        float y = (mc.devHeight - 60 * 10) / 2;

        apple = new Button[15 * 10];

        for (int i = 0; i < apple.Length; i++)
        {
            Button b = new Button();
            b.s = "" + UnityEngine.Random.Range(1, 10);
            b.rt = new Rect(x + 60 * (i % 15), y + 60 * (i / 15), 50, 50);
            b.cb = cGreen;//Color.green;
            b.ch = Color.yellow;
            b.cf = Color.white;
            b.pressed = false;
            b.size = 30;
            apple[i] = b;
        }

        score = new AutoNumber(0);
        _playTime = 120f;
        playTime = 120f;

        progressBar = new ProgressBar(new Rect(x, y - 40, 950, 30));
        progressBar.bc = Color.clear;
        progressBar.fc = Color.red;
        progressBar.lineWidth = 2f;
        progressBar.curr = 0;
        progressBar.max = 2000;
        progressBar.rv = this;

        gameOver = false;
        btnResult = new Button[2];
        string[] s = new string[2] { "다시시작", "나가기" };
        for (int i = 0; i < btnResult.Length; i++)
        {
            Button b = new Button();
            b.s = s[i];
            b.rt = new Rect(500 + 120 * i, 350, 100, 50);
            b.cb = Color.blue;
            b.ch = Color.black;
            b.cf = Color.white;
            b.pressed = false;
            b.size = 30;
            btnResult[i] = b;
        }
    }

    void freeIngame()
    {

    }

    void drawIngame(float dt)
    {
        for (int i = 0; i < apple.Length; i++)
        {
            if (apple[i].s == "0")
                continue;
            drawButton(apple[i]);
        }

        if (drag)
        {
            setRGBA(0, 0, 1, 0.5f);
            Rect rt = dragRect();
            fillRect(rt.x, rt.y, rt.width, rt.height);
            setRGBA(1, 1, 1, 1);
            //setLineWidth(1);
            //drawRect(rt.x, rt.y, rt.width, rt.height);
        }

#if false
        setRGBA(1, 0, 0, 1);
        setLineWidth(2);
        float x = (mc.devWidth - 60 * 15) / 2;
        float y = (mc.devHeight - 60 * 10) / 2;
        float w = 950;
        drawRect(x, y - 40, w, 30);
        w *= (float)score.get() / 2000;
        fillRect(x, y - 40, w, 30);
        setRGBA(1, 1, 1, 1);
#else
        //progressBar.curr = score.get();
        progressBar.curr = score;
        progressBar.paint(Time.deltaTime);
#endif

        setStringName("고딕체");
        setStringSize(30);
        setStringRGBA(1, 0, 0, 1);
        score.update(Time.deltaTime);
        drawString("Score : " + score.get(), mc.devWidth - 10, 10, TOP | RIGHT);

        setRGBA(0, 1, 0, 1);
        float h = mc.devHeight - 100;
        float dh = h * playTime / _playTime;
        fillRect(mc.devWidth - 20, 50 + h - dh, 5, dh);
        drawRect(mc.devWidth - 20, 50, 5, h);
        setRGBA(1, 1, 1, 1);

        playTime -= dt;
        if (playTime <= 0f)
        {
            gameOver = true;
        }

        if (gameOver)
        {
            setStringName("고딕체");
            setStringSize(100);
            setStringRGBA(1, 0, 0, 1);
            drawString("Score : " + score, 400, 200, TOP | LEFT);

            for (int i = 0; i < btnResult.Length; i++)
                drawButton(btnResult[i]);
        }
    }

    bool drag = false;
    float sx, sy, ex, ey;
    Rect dragRect()
    {
        float x0, x1, y0, y1;
        if (sx < ex) { x0 = sx; x1 = ex; }
        else { x0 = ex; x1 = sx; }
        if (sy < ey) { y0 = sy; y1 = ey; }
        else { y0 = ey; y1 = sy; }
        return new Rect(x0, y0, x1 - x0 - 1, y1 - y0 - 1);
    }

    public void mouseIngame(int state, float x, float y)
    {
        if (mouseGameOver(state, x, y))
            return;

        if (state == 0)
        {
            sx = ex = x;
            sy = ey = y;
            drag = true;
        }
        else if (state == 2)
        {
            drag = false;

            int sum = 0;
            for (int i = 0; i < apple.Length; i++)
            {
                if (apple[i].pressed)
                {
                    int n = Int32.Parse(apple[i].s);
                    sum += n;
                }
            }
            if (sum == 10)
            {
                Debug.Log("제거하자");
                for (int i = 0; i < apple.Length; i++)
                {
                    if (apple[i].pressed)
                    {
                        apple[i].s = "0";
                        score.add(100);
                    }
                }
            }
            else
            {
                for (int i = 0; i < apple.Length; i++)
                {
                    if (apple[i].pressed)
                        apple[i].pressed = false;
                }
            }
        }
        else if (drag)
        {
            ex = x;
            ey = y;

            Rect rt = dragRect();

            for (int i = 0; i < apple.Length; i++)
                apple[i].pressed = false;
            for (int i = 0; i < apple.Length; i++)
            {
                if (containRect(rt, apple[i].rt))
                {
                    if (apple[i].s != "0")
                        apple[i].pressed = true;
                }
            }
        }
    }

    bool mouseGameOver(int state, float x, float y)
    {
        if (gameOver == false)
            return false;

        switch (state)
        {
            case 0:
                for (int i = 0; i < btnResult.Length; i++)
                {
                    if (btnResult[i].pressed)
                    {
                        if (i == 0)
                        {
                            // 다시시작
                            for (int j = 0; j < apple.Length; j++)
                            {
                                apple[j].s = "" + UnityEngine.Random.Range(1, 10);
                                apple[j].pressed = false;
                            }
                            score.set(0);
                            playTime = _playTime;
                            gameOver = false;

                        }
                        else
                        {
                            // 나가기
                            gameState = 0;
                            freeIngame();
                            loadTitle();
                        }
                        break;
                    }
                }
                break;
            case 1:
                for (int i = 0; i < btnResult.Length; i++)
                    btnResult[i].pressed = containPoint(x, y, btnResult[i].rt);
                break;
        }

        return true;
    }
}






- AutoNumber : 값이 단계를 거쳐 변화도록 구현

- 프로그래스바

using UnityEngine;

public class AutoNumber
{
    int number;
    int numberS, numberE;
    float delta, _delta;

    public AutoNumber(int v, float duration = 0.3f)
    {
        number = v;
        _delta = duration;
        delta = duration;
    }

    // 객체가 같은지, 값이 같은지 구분
    public override bool Equals(object obj)
    {
        return base.Equals(obj);
    }
    public override int GetHashCode()
    {
        return base.GetHashCode();
    }
    public static bool operator ==(AutoNumber a, AutoNumber b)
    {
        return a.get() == b.get();
    }
    public static bool operator !=(AutoNumber a, AutoNumber b)
    {
        return a.get() != b.get();
    }

    // int n = an;
    public static implicit operator int(AutoNumber p)
    {
        return p.get();
    }
    // AutoNumber an = (AutoNumber)5;
    public static explicit operator AutoNumber(int n)
    {
        return new AutoNumber(n);
    }

    public static AutoNumber operator +(AutoNumber a, AutoNumber b)
    {
        AutoNumber an = new AutoNumber(a.number);
        an.add(b.number);
        return an;
    }
    public static AutoNumber operator +(AutoNumber a, int b)
    {
        AutoNumber an = new AutoNumber(a.number);
        an.add(b);
        return an;
    }
    public static AutoNumber operator -(AutoNumber a, AutoNumber b)
    {
        AutoNumber an = new AutoNumber(a.number);
        an.add(-b.number);
        return an;
    }
    public static AutoNumber operator -(AutoNumber a, int b)
    {
        AutoNumber an = new AutoNumber(a.number);
        an.add(-b);
        return an;
    }

    // ++, --
    public static AutoNumber operator ++(AutoNumber a)
    {
        a.add(1);
        return a;
    }
    public static AutoNumber operator --(AutoNumber a)
    {
        a.add(-1);
        return a;
    }

    public void set(int v)
    {
        number = v;
    }

    public void add(int v)
    {
        //number += v;
        if (delta < _delta)
        {
            numberS = get();
            numberE = numberE + v;
        }
        else
        {
            numberS = number;
            numberE = number + v;
        }
        delta = 0.0f;
    }

    public int get()
    {
        if( delta < _delta )
        {
            float r = delta / _delta;
            return (int)(numberS * (1.0f - r) + numberE * r);
        }
        return number;
    }

    public void update(float dt)
    {
        if( delta < _delta)
        {
            delta += dt;
            if( delta >= _delta )
            {
                delta = _delta;
                number = numberE;
            }
        }
    }
}
